Hyundai H 100 High Deck 2023 Price in Pakistan & Specs

4th Generation


2607 cc


77 HP @ 4000 RPM


167 Nm @ 2200 RPM

Key Specifications of Hyundai H 100 High Deck

Key Features of Hyundai H 100 High Deck

Hyundai H 100 High Deck Colors


Hyundai H 100 High Deck Brochure Specs and Features

See latest and brand new Hyundai H 100 High Deck full specs with all the features in detail.
2.6L Euro II diesel natural aspirated
Bore x Stroke mm
91.1 x 100
Compression Ratio
22 : 1
Max. Power ps/rpm
79 @4,000
Max. Torque nm/rpm
167 @ 2,200
Valve System
Single overhead camshaft, 2 valves / cylinder
Fuel System
Min-Max type governor, bosch type injection pump
Fuel type
Fuel Tank l
Double Wishbone & Torsion Bar with ø 25mm Stabilizer Bar
Semi-elliptic Laminated Leaf Springs
Load apacity
Load Area
4539 mm2
Maximum Towing Weight Braked Trailer
1 Ton
Hydraulic Power Assisted Rack and Pinion with Collapsible Universal Joint and Column
Minimum Turning Radius m
Wheels and Tyres
Steel Rim 6.0J x 15”
Tyre mm
195 / 70 R15 C
Spare Tyre
Full Size Steel Rim
Front mm
ø 274 mm Ventilated disc
Rear mm
ø 260 mm Solid Drum
Load Sensing Proportioning Valve
Brake Booster
8 + 9” Tandem
5 speed Manual
Show More Show Less

Hyundai H 100 High Deck Specifications

Kerb Weight - No of Doors 2 doors
Overall Height 1970 mm / 6'6" feet Overall Length 4850 mm / 15'11" feet
Overall Width 1740 mm / 5'9" feet Wheel Base 2430 mm / 8'0" feet
Ground Clearance -
Cylinder Configuration In Line Displacement 2607 cc
Engine Power 77 HP @ 4000 RPM Fuel System Min-Max type governor, bosch t
Torque 167 Nm @ 2200 RPM Valve Mechanism SOHC 8 Valves
Valves per Cylinder 2 Compression Ratio 22
Assembly Local Warranty 4 Years 100000Km
No of Cylinders 4 Fuel Grade -
CO2 Emission - Bore/stroke (mm) 91.1 x 100
Minimum Turning Radius 5.3 m Steering Type Rack & Pinion with Hydraulic Pump
Power Assisted Hydraulic Power Steering Steering Switch -
Tire / Tyre Size 195/70/R15 Wheel Size 15 in
PCD 5 x 120 mm Wheel Type Steel Rims
Mileage City 0 KM/LITER Mileage Highway KM/LITER
Gearbox 5-speed
Suspension Front: Double Wishbone, Rear: Leaf Spring City driveability (20-80 kmph) -
Top Speed 180 KM/H Drive Modes -
Parking Sensors - Acceleration 0-100kmph -
Headlights - Day Time Running Lights (DRL) -
Brakes Front: Ventilated Disc Rear: Drum Braking (100-0 kmph) -
Braking (80-0 kmph) -
Drive Type All wheel drive Drive Setup Driver right
Brochure Download Waiting Time (Own) 1 Month
Release Date 30 November -0001 Category Vans / Trucks up to 7.5 t
Outer Door handle finish Black Door Visor
Multi Information Combination - Seats, Armrests & Door Lining Inserts Fabric
Interior Color - Insight Door Handles -
AC Vent Knobs - Hand Brake Knob -
Antenna - Inner Lights Yes
Supervision Cluster / Driver Multi Information System -
Sound System / Speakers Front Speakers USB Charger -
Infotainment / Funtainment System / Audio System -
Axels - Licensed Weight -

Comfort & Convenience

CoolBox Cup Holders
Power Seats / Seat Adjustment Remote Boot/Fuel-Lid
Steering Adjustment Sun-Roof | Moon-Roof |
Cruise Control Keyless Entry
Power Mirror Remote Keyless Entry
Heated Seats USB and Auxillary Cable
Climate Control Rear AC Vents
Steering Switches Arm Rest
Multi Info Optional Navigation
Vanity Mirror Accessory Power Outlet
Seat Lumbar Support Smart Access Card Entry
Voice Control Steering Wheel Gearshift Paddles
Central Console Armrest Tailgate Ajar Indicator / Trunk Warning
Power Windows Wiper Tinted Glass
Traffic Jam Assist Navigation System / GPS System
Rear Ventilation Terrain Response System
Air Conditioner Remote Trunk Opener / Tailgate
Fast Charging Auto door lock with speed
Brake Override System (BOS) / Smart pedal Smart Entry
Auto A/C Wifi Hotspot
Voice Command Dust & Pollen Air Filter / Air Purifier
Digital Clock Outside Temperature Display
Smart Welcome System Refrigerator Compartment
Cabin Watch Cabin Talk
Adaptive Cruise Control Lane Winker
Remote Windows / Smart Key Open Close


Defogger Tachometer
Third Row Seats Defogger
Rear Window Defroster Folding Rear-Seat
Leather Interior Rear Seat Headrest
Heater Interior Lighting
Isofix Seat/ Child Seat Front Map Lamps


Alloy Rims Leather Seats
Front Fog Lights Leather Seats
Alloy Rims Rear Window Wiper
Front Fog Lights Adjustable Headlights / Headlights Leveling
Auto Wiper / Rain Sensing Wiper Power Antenna
Removable/Convertible Top Roof Carrier
Side Stepper Outside Rear View Mirror Turn Indicators
Integrated Antenna Chrome Grille
Tow Package Chrome Garnish
Smoke Headlamps Roof Rail
Heated Wing Mirror Rear Spoiler
Outside Mirror Spare wheel
Trunk LID Lining


Power Door Locks Alarm System Anti-Lock
Brakes Fog lights Immobilizer Key
Traction Control System TCS Child Lock
Rear Power Windows / Electric Windows Automatic Emergency Braking
Intelligent Speed Assist System Lane Departure Warning
Rear Seat Belts Electronic Brake Assist EBA
Tyre Pressure Monitor System RPMS Vehicle Stability Control
Anti-Theft Device Central Locking
Speed Alert Crash Sensor
Hill Assist / Hill Hold Control / Downhill Brake Control (HHC/ HAC / DBC) Anti-Pinch Power Windows
Blind Spot Monitor Security System
Hill Descent Control Automatic Headlamps/ Automatic Headlights
High Mount Stop Lamp Electronic Parking Brake
Vehicle Stability Management Driver Condition Monitor
Wade Sensing Rear Pre-collision Monitor
3D Surround Camera Road Sign Assist
Vehicle Running Recorder / Trip Recorder

Entertainment & Communication

AM/FM Radio CD Player
Cassette Player Premium Sound
Rear Seat Entertainment iPod/MP3 compatible


Spotlights Winch
Hydraulic platform
