Performance
Engine power	50 (B.S) hp*@2,250
Torque	172 Nm@1,400 engine rpm
PTO Power	44 hp**@ engine speed
Engine
Type	Diesel /AD 3,1524
No. of cylinders	3
Injection	Direct
Bore	91.5 mm
Stroke	127.0 mm
Capacity (litres)	2.5
Compression ratio	16.5:1
Aspiration	Natural
Starting aid	Thermostart
Throttle control	Hand and foot
Cooling	Water
Air Cleaner Type	Oil bath
Air Pre-Cleaner	Over bonnet
Fuel filter	Dual, high capacity
Exhaust	Vertical
Electrics
Voltage	12V, Negative Earth
Battery	118 Ah
Starter Motor	2.2 kW
Alternator	32 Amp.
Clutch
Type	Dual clutch
Diameter	305x254 mm
Transmission
Type	Sliding spur
Number of gears	8 forward 2 revers
Gear	Speed (km/hr)
Forward 1 (first low)	2.5
Forward 2	3.7
Forward 3	5.0
Forward 4	6.7
Forward 5 (first high)	10.0
Forward 6	14.7
Forward 7	20.1
Forward 8	27.0
Revers 1 (low)	3.4
Revers 2 (high) Power Take Off	13.6
Type	Live
Engine speed	1,789 rpm@ 540 PTO rpm
Shaft diameter	35 mm
No. of splines	6
hydraulics
Functions	Draft control, Position control, Response Control, Constant pumping
Pump Type	Reciprocating Ferguson Pump
Oil Flow	162/ min
Pressure	19.2 Mpa
Lift capacity with lower links horizontal	1,415 kg
Lower links	With cat . I & II interchaneable balls
Front Axle
Type	Box Section, Adjustable
Steering
Steering	Manual
REAR AXLE AND BRAKES
Brake Type	Outboard drum brakes
Actuation	Mechanical, Independent or locked together
Parking Brake	Hand lever operated
Differential lock	Mechanical
Instrumentation
Gauges	Tachometer, Hourmeter, Fuel level, Battery condition & Water temperature
Warning lights	Direction Indecators, battery charge,headlight main beam,low engine oil pressure,brake lights & auxiliaty socket
Tyres
Front	6.00-16(6rp)
Rear	12.4/11-28 (6 Rp)
TRACK ADJUSTMENT
Front	1,245 - 1,854 mm
Rear	1,219 - 1,930 mm
*WEIGHTS AND DIMENSIONS ()**
Weight
Gross Weight	1,650 kg
Dimensions
Wheel base	1,892mm
Overall length	3,260mm
Overall width (min)	1,651mm
Height
Over exhaust	2,145mm
Over steering wheel	1,410mm
Turning circle
With brakes	5,560mm
Without brakes	6,200mm
Ground Clearance
(Under gear box)	338 mm
Capacities
Fuel Tank	47.5
Engine sump	6.8
Cooling system	10.2
Hydraulic system	33.0
Steering box	0.9
oil bath air - cleaner	0.65
STANDARD EQUIPMENT
STANDARD EQUIPMENT	Weight frame without weights, Standard tool box with set of tools, Top link, Top link end Cat! & II balls, Check Chains, Spring suspension seat, Flat top fenders & Operator’s and service manual.
OPTIONAL EQUIPMENT
OPTIONAL EQUIPMENT	Front end weights, Swinging drawbar, Sun Canopy, Pintle Hook and 9 Hole drawbar.
