Performance
Engine power	85 (B.S) hp*@2,200 rpm
Torque	300 Nm@1,400 engine rpm
PTO Power	70 hp**@ engine speed
Engine
Type	Diesel / 4.41
No. of cylinders	4
Injection	Direct
Bore	101 mm
Stroke	127 mm
Capacity (litres)	4.1 L
Compression ratio	15.3:1
Aspiration	Natural
Starting aid	Thermostart
Throttle control	Hand and foot
Cooling	Water
Air Cleaner Type	Oil bath
Air Pre-Cleaner	Over bonnet,air swirl
Fuel filter	Dual, high capacity with sendimentor
Exhaust	Vertical muffler under bonnet
Oil Cooler	Water Cooled
Electrics
Voltage	12V, Negative Earth
Battery	118 Ah
Starter Motor	2.8 kW
Alternator	45 Amp.
Clutch
Type	Dual
Diameter	305x254 mm
Lining material	Cerametallic
Transmission
Type	Sliding spur
Number of gears	8 forward 2 revers
Gear	Speed (km/hr)
Forward 1 (first low)	2.9
Forward 2	4.2
Forward 3	5.8
Forward 4	7.8
Forward 5 (first high)	11.6
Forward 6	17.0
Forward 7	23.13
Forward 8	31.0
Revers 1 (low)	4.0
Revers 2 (high)	15.7
Power Take Off
Type	Live
Engine speed	1,789 rpm@ 540 PTO rpm
Shaft diameter	35 mm
No. of splines	6
hydraulics
Functions	Draft control, Position control, Response Control, Constant pumping
Pump Type	4 Piston , ferguson pump
Oil Flow	16.7 l / min
Pressure	21 Mpa at normal operating temp.
Lift capacity with lower links horizontal	2,145 kg
Lower links	cat . I & II interchaneable balls
Front Axle
Type	Parallel Drive
Engagement	Mechanical
Steering
Type	Hydrostatic
REAR AXLE AND BRAKES
Axle Type	Straddle with epicyclic reduction unit
Brake type	Oil Immersed,multi-disc
Brake pedal	Pendant
Brake area	1,774 sq.cm
Brake actuation	Hydraulic
Parking brake	Hand lever operated
Instrumentation
Gauges	Tachometer, Hourmeter, Fuel level, Battery condition & Water temperature
Warning lights	Direction indicators, Electric charge, Headlight main beam, Low engine oil pressure 4WD indecation light & auxiliaty socket
Tyres
Front	12.4/11-24 (12 PR)
Rear	18.4/15-30 ( 8 PR )
TRACK ADJUSTMENT
Front Axle	1,376 – 1944 mm
Rear Axle	1,423- 2,134 mm
*WEIGHTS AND DIMENSIONS ()**
Weight
Gross Weight (Approx)	2,760 kg kg
Dimensions
Wheel base	3,810 mm
Overall length	1,871 mm
Overall width	2,350 mm
Height
Over exhaust	2,485 mm
Over steering wheel	1,781 mm
Turning circle
With brakes	8,518 mm
Ground Clearance
(Under gear box)	501 mm
Under 4WD front Axle	395 mm
Capacities
Fuel Tank	108.0 l
Engine sump	7.5 l
Cooling system	15.2 l
Hydraulic system	47.4 l
Hydraulic steering reservoir	2.0 l
Brake oil	0.7 l
oil bath air – cleaner	0.25
4WD Front axle differential	5.6
Hub each side	1.0
STANDARD EQUIPMENT
STANDARD EQUIPMENT	Weight frame without weights, Standard tool box with set of tools, Top link, Top link end Cat – l & ll balls, Check Chains,stabiliser chains Spring suspension seat, Flat top fenders, & Operator’s Service Manual.
OPTIONAL EQUIPMENT
OPTIONAL EQUIPMENT	Front end weights, Swinging drawbar, Sun Canopy, Pintle hook and 9 Hole drawbar.
