FAW J5M 220 Super Plus 4X2 Rigid 2022 Price in Pakistan & Specs

Engine

6557 cc

Horsepower

220 @ 2300

Torque

770 @ 1400

Key Specifications of FAW J5M 220 Super Plus 4X2 Rigid

Key Features of FAW J5M 220 Super Plus 4X2 Rigid

FAW J5M 220 Super Plus 4X2 Rigid Colors

Maroon

White

Yellow

FAW J5M 220 Super Plus 4X2 Rigid Brochure Specs and Features

See latest and brand new FAW J5M 220 Super Plus 4X2 Rigid full specs with all the features in detail.
Mass
Permissible G .C .W (Kg)
28,500
Axle Load Distribution (kg)
Front
6,500
Rear
22,000
Chassis Weight (kg)
Total
7,800
Front
3,800
Rear
4,000
Performance
Max. Speed (km/h)
85
Max. Gradeability (%)
32
Fuel tank capacity (L)
400
Engine
Model
FAWDE CA6DF2D-22
Type
Diesel,4 stroke in line , 6 cylinders , water cooled, turbo charged with inter cooler
Displacement (cc)
6557 (6.5 litre)
Bore
110X115
Emission
Euro ll
Transmission
Mode
FAW CA7TB1OOM
Type
7 forward 1 reverse ( inclusive of ‘C’ Gear)
Gear ratio
i1=10.120/i2=7.270/ i3 = 4.310/ i4=2.718/ i5 = 1.826/ i6=1.342/ i7=1.000
Reverse shift ratio
lr = 9.397
Clutch
Type
Eaton dry type.single plate,diaphragm spring clutch, hydraulic controlled and air aided power operating
Driven plate dia.
Ø 395 (15.5)
Axles
Front
Reverse elliot “l” section beam
Rear
FAW single reduction
Ratio
5.28 (7/37)
Brakes
Driving brake
Full air dual circuit brake
Parking brake
Spring energy storage type
Auxiliary brake
Exhaust brake
Steering

Model/ type
Recirculating ball-type steering, integrated power steering
Cab
Type
Cab over engine,front tilting 44 angle
Suspension
 2-point hydraulic suspension
Seats type
Mechanical suspension seat with 3-point seat belt
Seating capacity
2
Dimensions
Length (mm)
9845
Width (mm)
2490
Height (mm)
2720
Length behind cab (mm)
7718
Wheel base (mm)
4725 + 1350
Min.Ground clearance
298
Front overhang (mm)
1375
Rear overhang (mm)
2935
Suspension
Front
Semi-elliptic multi-leaf springs
Rear
Semi-elliptic,multi-leaf main springs with auxiliary springs
Wheel
Rim
8.00-20
Wheel type
Stud- pilloted 10-hole steel disc
Tyre Size
11.00-20R
No.of Tyres
11
Turning Radius (m)
8.5
Frame
Type
Side Rails. Punching & riveted construction
Main rail section
280x90x8
Electrical & Lights
Type
Earth return system ,negative earthed,
Battery (V/Ah)
2x12V/150
Generator
1200 W
Show More Show Less

FAW J5M 220 Super Plus 4X2 Rigid Specifications

Kerb Weight - No of Doors 2 doors
Overall Height 2720 mm / 9'0" feet Overall Length 9845 mm / 32'4" feet
Overall Width 2490 mm / 8'3" feet Wheel Base 6075 mm / 20'0" feet
Ground Clearance 298 mm / 1'0" feet
Cylinder Configuration In Line Displacement 6557 cc
Engine Power 220 @ 2300 Fuel System Water cooled turbo charged
Torque 770 @ 1400 Valve Mechanism -
Valves per Cylinder - Compression Ratio -
Assembly Imported Warranty 2 Years or 120000Km
No of Cylinders 4 Fuel Grade -
CO2 Emission Euro II Bore/stroke (mm) -
Minimum Turning Radius 8.5 m Steering Type Recirculating ball type steering
Power Assisted Integrated power steering Steering Switch -
Tire / Tyre Size 11-00-20R Wheel Size 20 in
PCD mm Wheel Type Stud piloted 08 hole steel disc
Mileage City 0 KM/LITER Mileage Highway KM/LITER
Gearbox 7-speed
Suspension Front: Semi Elliptic multi leaf, Rear: Semi Elliptic multi leaf main springs with auxiliary springs City driveability (20-80 kmph) -
Top Speed 85 KM/H Drive Modes -
Parking Sensors - Acceleration 0-100kmph -
Headlights - Day Time Running Lights (DRL) -
Brakes Driving Brake, Parking Brake, Auxiliary Brake Braking (100-0 kmph) -
